Drop Tester

FEATURES

• Motor hoist with hand held control box to automatically raise and lower drop arm with package on drop arm.
• Microswitch to set drop height for repeatable drops.
• Drop Height Indicator
• Remote hand switch actuated
• One inch vertical drop prior to drop arm swing to insure that package not subject to rotation.


OPTIONS

• Corner and Edge Drop Fixture
• Additional Drop Height
• Digital Instrumentation

OPERATION

Attach 80psig plant air into the valve attached to the base using the quick disconnect fitting. Set the microswitch to the desired drop height. Place the package on the drop arm and raise to pre-set height using the hand held control box. To drop package, initiate the hand switch.


Portable Drop Tester

FEATURES

• Flange supplied to attach to table top
• Mechanism may be rotated to drop specimen either on the floor or on to table top
• Drop arm assembly may be adjusted manually.
• Drop Height Indicator
• Hand switch actuated
• One-quarter inch vertical drop prior to drop arm swing to insure that package is not subject to rotation
• Corner and Edge Drop Fixture
